Solidworks Motion Study Tutorials | using Rotary Motor

Motors are Motion Study elements that move components in an assembly by simulating the effects of various types of motors.

in this tutorials, we explain how to add a motor to move Box "B" by rotating Arm "A" 117.5 degrees ( 160-42.5) in certain time 10 seconds

Download Project files...

Open "wood toy truck-Assembly"

Start New Motion Study and click on " Motor " icon

and click on " Motor " icon
To open the Motor PropertyManager
>>>>> set motor location at a point "O"
>>>>> set motor function as distance

>>>>>> Eidt key point time 10s

>>>>> Finally calculate the motion study
